Sensor
• Type: Uncooled VOx (vanadium oxide)
• Resolution (pixels): 256 × 192
• Pixel size: 12 × 12 μm • NETD: ≤ 15 mK (0.015 °C)
• Refresh rate: 50 Hz
• Detection range: Up to 1200 meters ⸻ Optics
• Lens: 25 mm • Optical magnification: 3.6×
• Digital zoom: 2× / 4× / 6× / 8× Field of view:
• Horizontal: 7° • Vertical: 5.3°
• Diagonal: 8.8° Field of view at 100 m:
• Horizontal: 12.3 m • Vertical: 9.2 m
• Focus range: 5 m to infinity
• Eye relief: 50 mm
• Diopter adjustment: -5 to +5 ⸻ Display • Type: OLED
• Resolution: 1920 × 1080

Connections • USB Type-C: Yes
• HDMI output: No
• WiFi: Yes
• Supported apps: PardVision2

Power supply • Battery type: Lithium-ion 18650 × 1
• Output voltage: 3.7 V
• Operating time: Up to 5 hours
• External power supply: USB Type-C

Environmental properties
• Protection class: IP67
• Operating temperature: -30 °C to +55 °C
• Recoil resistance: 6000 J
Material
• Housing: Aluminum alloy
• Lens: All-glass, multi-coated lens
Dimensions and weight
• Dimensions (L × W × H): 295 × 82 × 70 mm
• Weight (incl. battery): 500 g
